ROHN JRMPAD1
In-Stock Free Shipping!
HRO Discount Price: $324.95*
*After Coupons & Promotions.
SOLID STATE ELECTRONICALLY REGULATED
FOLD BACK CURRENT LIMITING Protects Power Supply from excessive current and continuous shorted output
CROWBAR OVER VOLTAGE PROTECTION ON ALL MODELS
MAINTAIN REGULATION AND LOW RIPPLE at low line input Voltage
THREE CONDUCTOR POWER CORD
HEAVY DUTY HEAT SINK
INPUT VOLTAGE: 105-125VAC
EXTERNALLY ADJUSTABLE VOLTAGE: 2-15VDC
RIPPLE: LESS THAN 5MV PEAK TO PEAK (full load and low line)
LOAD REGULATION: 0.08% from 0 to Full Continuous Load??
EFFICIENCY: 77%
OPERATING TEMP: -10 to 55°C
220V MODELS AVAILABLE BY SPECIAL ORDER
CONTINUOUS DUTY:
@13.8VDC: 25 Amps?
@10.0VDC: 15 Amps
@05.0VDC: 7 Amps
ICS*:
@13.8VDC: 35 Amps?
@10.0VDC: 16 Amps
@05.0VDC: 8 Amps
DIMENSIONS: 5 x 11 x 11"
SHIPPING WEIGHT: 29 lbs
FUSE: AGC 8A
POWER TERMINALS:
1/4"-20 Screw Type
AC POWER DRAW:
IDLE: 320mA
FULL LOAD: 5.7a
FAN COOLED: No
