MOMOBEAM MONO6 6
MOMOBEAM-MONO6 6-Image-1 MOMOBEAM-MONO6 6-Image-2

MOMOBEAM MONO6 6

Yagi Monoband 6 el. 6 Meters

HRO Discount Price: $599.95*



*After Coupons & Promotions.

Current Stock Status At These Ham Radio Outlet Locations
Anaheim, CA
Atlanta, GA
Denver, CO
Milwaukee, WI
New Castle, DE
Phoenix, AZ
Plano, TX
Portland, OR
Sacramento, CA
Salem, NH
Winter Springs, FL
Woodbridge, VA
MONO6 6 Description     Hide

MONO6 6 is our six elements high performance antenna for the MAGIC BAND of 50 Mhz.

With only 9 kg/20 lb in weight, it is to handle during installations.

Thanks to its optimized size and spacing elements, it easily covers the most-used part of the band with a flat SWR curve of less than 1.5:1, excellent front-to-back ratio and excellent gain.

Its excellent mechanical characteristics, together with its excellent performance, make the MONO6 6 a perfect antenna even for the most demanding pileups.

Requires a rotor for light load


SPECIFICATIONS:

MONO6 6 Band 6 m
Gain dBi:
(20 meters above the ground)		 17.3
Gain dBd free space: 9.55
F/B dB: 25
Active elements: 6
Bandwidth KHz
S.W.R. ≤ 1.5:1		 500
Boom Length: 645 cm/21 ft
Turning radius: 400 cm/13 ft
Feed line required: 1 X 50 Ohm
Max tower lift side: 60 cm/2 ft



  • Longest element: 300 cm/9.85 ft
  • Power handling: 10 KW
  • Wind area: 0.35 m²/3.76 sq ft
  • Wind survival*: 100 Km/h/ 55 MPH
  • Mast diameter: 50 mm/2 inch (larger on request)
  • Balun: 2 KW included
  • Weight (excluding packaging): 9 Kg/20 lb


MATERIALS USED:

  • Tubes and plates: Aluminum alloy 6060T6
  • Hardware: stainless and galvanized steel
  • Insulating clamps: polypropylene UV resistant



Manual:  English
